Outdoor Central Chiller

Outdoor Central Chillers

Centralized Cooling SystemsCentralized Cooling Systems

Download Datasheet

Outdoor Air-Cooled Central Chillers from Mokon are designed for exterior installation, freeing up valuable indoor equipment space. Systems are available from 20 Ton capacities and larger.

Mokon Outdoor Central Chillers are compact, completely factory wired, and have easy lifting provisions for quick and trouble-free installation. They are factory tested and arrive on site in complete working order, eliminating any potential start-up problems. When combined with a Mokon pump tank, they provide a highly engineered quality solution to your plant chilled water problem.

Each chiller features the most advanced microprocessor chiller control technology and components to provide you with the highest degree of accuracy and ease-of-use while in operation. Optional control interfaces are available.

Through simple design, these chillers are engineered to give you lower life cycle costs and increased reliability.

Request for Quote?
All of our products can be customized.

Start Here
Outdoor Central Chillers

CGAM – 20 TO 120 TON CAPACITIES

  1. Air-cooled condenser with direct-drive vertical condenser fans
  2. Designed for outdoor ambient temperature of 0 to 125°F (fluid temperature 10 to 60°F)
  3. Superior EER ratings
  4. Small footprint with easy lifting provisions
  5. Microprocessor-based controls
  6. Hermetic direct-drive scroll compressors
  7. Highly efficient brazed plate evaporator with Armaflex insulation and heat tape
  8. Evaporator indication
  9. Condenser coil guard
  10. Advanced motor protection
  11. Loss of flow protection
  12. Low ambient lockout
  13. Smart lead/lag operation
  14. Flow switch and water strainer factory installed
  15. R-410A refrigerant
  16. Completely factory wired and tested
  17. Easy-to-access electrical and water connections
  18. LON, BACNet, or generic BAS interface options
RTAC

RTAC – 140 TO 500 TON CAPACITIES

  1. Air-cooled condenser with direct-drive vertical condenser fans
  2. Designed for outdoor ambient temperature of 0 to 115°F (fluid temperature 10 to 60°F)
  3. Superior EER ratings
  4. Hermetic direct-drive rotary compressors
  5. Two independent refrigerant circuits
  6. Microprocessor-based controller +/– 1/2°F control capability (leaving water temperature)
  7. Variable compressor modulation to match capacity and offer better compressor control
  8. Meet efficiency levels of ASHREA Standard 90.1
  9. Highly efficient brazed plate evaporator with Armaflex insulation and heat tape
  10. Low sound levels
  11. Loss of flow protection
  12. Low ambient control
  13. 134A refrigerant
  14. Small footprint

Warranty

  • 1 year on system

Please contact Mokon for more information.

Please contact Mokon for more information.
