Chiller Systems

Blown Film Cooler Series

blown film cooler
blown film cooler

Mokon's BFC Series blown film air coolers offer an increase in blown film activity, especially in warmer climates or when ambient air temperatures rise during the summer. The BFC Series boosts productivity by eliminating production variables in your air ring supply, including air temperature, pressure, and volume.

The BFC units typically use a modulated chilled water supply to provide a constant leaving air temperature to the process. The air inlet diffuser assures that the air stream covers the full face of the cooling coil to provide optimum cooling efficiency. The leaving air chamber is insulated to reduce condensation while providing the coldest air possible to the air ring.

Download Datasheet Request a Quote
  • Nonferrous wetted surfaces
  • Insulated powder coated internal and external heavy gauge steel cabinet
  • Zinc plated bolts spaced for 35″ static pressure
  • Permanent cleanable filter
  • Discharge air temperature gauge
  • Drip condensate trap
  • Coil air vent
  • Entering air diffuser
  • Adjustable bolt-on support legs
  • Dial thermometers for chilled water inlet, chilled water outlet, and leaving air
  • Chilled water flow control ball valves

Warranty

  • 1 year warranty on system
  • Lifetime on cabinet
  • Custom air inlet/out transitions
  • Custom painted colors
  • 5°F (-15°C) approach coil
  • Other voltages, phase, frequencies
  • Stackable designs
  • Static pressure blower with controls
  • Two or three-way modulating valves

Please consult factory for more information.

Model Process Air CFM BTU/Hr of Heat Removal1 Nominal Cooling Required (Tons)2 Water Capacity (gpm) Chilled Water Connection Air Inlet/Outlet Optional Blower Motor 3 16″ Static Pressure (Hp) Optional Blower Motor 3 35″ Static Pressure (Hp) Approx. Dimensions (L x W x H) Base Shipping Weight (Approx. lbs) Shipping Weight with 16″ Blower (Approx. lbs) Shipping Weight with 35″ Blower (Approx. lbs)
BFC-600 600 64,512 5.5 13 1″ 10/10 3 7.5 47″ x 32″ x 47″ 400 690 790
BFC-1000 1000 105,855 9.0 26 1 1/2″ 10/10 5 10 47″ x 32″ x 47″ 430 705 830
BFC-1500 1500 158,861 13.5 40 2″ 14/14 7.5 15 47″ x 38″ x 51″ 645 985 1215
BFC-2000 2000 211,775 18.0 59 2″ 14/14 10 20 47″ x 38″ x 51″ 700 1050 1325
BFC-3500 3500 370,470 31.0 81 2 1/2″ 16/16 15 40 60″ x 45″ x 74″ 1100 1580 2035
BFC-5000 5000 532,210 44.5 112 2 1/2″ 18/18 25 60 70″ x 64″ x 75″ 1600 2375 2575
BFC-7500 7500 793,760 66.0 126 3″ 22/22 40 75 70″ x 73″ x 84″ 1800 2575 3800
BFC-9000 9000 953,541 80.0 175 3″ 24/24 40 75 70″ x 73″ x 84″ 2000 3075 4300

  1. Based on 50°F (10°C) leaving air from cooler, 80°F (27°C) wet bulb ambient air temp, 40°F (4°C) entering chilled water and required CFM of process air.
    Note: Heat removal value does not include heat contributed by the blower
  2. Chilled water Tons required with entering air at 100°F (38°C) dry bulb, 80°F (27°C) wet bulb, 40°F (4°C) chilled water and 50°F (10°C) leaving air.
  3. Blower at 460 Volt, 3 Phase, 60 Hertz
